ARM / Android Panel PCs · Part no.
IAM2X156

IAM2X156 — 15.6″ ARM Panel PC

15.6″ 1366 × 768 ARM Panel PC with an IP65 front bezel.

The IAM2X156 is a 15.6″ ARM Panel PC with a 1366 × 768 TFT LCD panel. It is available with single-point resistive or 10-point capacitive front options. It has an IP65 front bezel, an aluminium-magnesium alloy housing and a 0 to 60 °C operating range. Power input is 12–24 V DC. Mounting options are embedded, VESA. It runs on a Rockchip RK3568 ARM processor.
Request a quote Datasheet (PDF) (opens in a new tab)
IAM2X156 front view
In production

Technical specifications

15 specs
Technical specifications
Product
Product familyIAM2X
Display
Display Size15.6inches
Resolution1366 × 768
Panel TypeTFT LCD
Capacitive touchYes
Resistive touchYes
Processing
CPURockchip RK3568
Memory2GB
Technical specifications
Power
Input Voltage (min)12V DC
Input Voltage (max)24V DC
Environmental
Operating Temperature (min)0°C
Operating Temperature (max)60°C
Ingress ProtectionIP65
Mechanical
Panel mountYes
VESA mountYes

Across the series

4 differences

Only the specifications that differ across this product line. Everything the models share is on the full specification table above.

Across the series
SpecificationIAM2X121IAM2X122IAM2X150This modelIAM2X156IAM2X170IAM2X173
DisplayDisplay Size12.1inches12.2inches15inches15.6inches17inches17.3inches
Resolution1024 × 7681280 × 8001024 × 7681366 × 7681280 × 10241920 × 1080
EnvironmentalOperating Temperature (min)-20°C-20°C-10°C0°C0°C0°C
Operating Temperature (max)70°C70°C65°C60°C50°C70°C
